26.965-27.405 MHz (EU - Europe), 26.565-27.405 MHz (D: Germany), 26.965-27.405 / 27.60125-27.99125 MHz (U: United Kingdom), 26.965-27.405 MHz (EC - Europe), 26.960-27.400 MHz (PL - Poland), 25.565-27.275 MHz (IN - Italy), 28.000-29.700 MHz (10 ham band), 25.615-30.105 MHz (Export).

Frequency range

RX-range
25.615-30.105 MHz (restricted in most countries)
TX-range
25.615-30.105 MHz (restricted in most countries)
HAM bands
11m (CB)  10m
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   FM
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
AM   FM
RF-Output
15 W (export), 4 W normal

Connections

Antenna
SO-239
Impedance
?

Electrical

Power requirements
13.8 or 24 V DC ± 10%
Current drain RX
?
TX
3 A max

Physical

Dimensions (w×h×d)
122 × 35 × 165 mm (4.80 × 1.38 × 6.50 in)
Weight
480 gr (1.1 lbs)
Form factor
Mobile
Manufactured
Between 2016 and 201x in China
MPN
3140650022063

Other features

Memories
400 channels in 1 bank(s)
Usage
Citizen Band (27Mc)
Features + options
Color screen
Accessories
?

Manuals, diagrams and brochures

CRT-2000 Owner's Manual submitted by RigReference
CRT-2000 Export Model Channels Mod submitted by RigReference

Upload relevant documents

Show other documents.
Find the CRT 2000 user manuals on eBay #ad

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of new a used CRT 2000. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the CRT 2000 is around:

  • EUR 124.00
Year Historic price Condition Submitted by
2019 EUR 124.95 New / Mint RigReference
