26.965-27.405 MHz (EU - Europe), 26.565-27.405 MHz (D: Germany), 26.965-27.405 / 27.60125-27.99125 MHz (U: United Kingdom), 26.965-27.405 MHz (EC - Europe), 26.960-27.400 MHz (PL - Poland), 25.565-27.275 MHz (IN - Italy), 28.000-29.700 MHz (10 ham band), 25.615-30.105 MHz (Export).
General characteristics
- HAM bands
- 11m (CB) 10m
- Frequency stability
- ?
- Tuning steps
- Channelized
- Memories
- 400 channels in 1 bank(s)
Receiver
- RX-range
- 25.615-30.105 MHz (restricted in most countries)
- Modulations
- AM FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 25.615-30.105 MHz (restricted in most countries)
- Modulations
- AM FM
- RF-output
- 15 W (export), 4 W normal
Connections
- Antenna
- SO-239
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 13.8 or 24 V DC ± 10%
- Current drain RX
- ?
- TX
- 3 A max
Physical
- Dimensions (w×h×d)
- 122 × 35 × 165 mm (4.80 × 1.38 × 6.50 in)
- Weight
- 480 gr (1.1 lbs)
- Form factor
- Mobile
- Manufactured
- Between 20xx and 20xx in China
Other features
- Usage
- Citizen Band (27Mc)
- Features + options
- Color screen
- Accessories
- -
- RigReference ID
- 6559
- MPN
- CRT-002000H
Manuals, diagrams and brochures
- CRT 2000H Owner's Manual PDF - 4.36 MB, submitted by Gerd
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used CRT 2000H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on similar Transceiver equipment, the estimated value of the CRT 2000H is around:
- USD 210 ~ USD 390
This estimate is based on similar equipment and may not reflect the exact value of this model.
These estimates are based on the following prices:
