Heathkit SA-2060A

Deluxe HF Antenna Tuner

View all reviews (0) Add a review Add to my shack



Login or Register to upload images

The Deluxe Antenna Tuner model SA-2060A combines the features of the Heathkit SA-2040 antenna tuner with the Heathkit HM-2140 dual watt-meter.

Frequency range

RX-range
1.8-30 MHz
TX-range
1.8-30 MHz
HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
All mode
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
All mode
RF-Output
200 / 2000 W

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
?
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
368 × 352 × 146 mm (14.49 × 13.86 × 5.75 in)
Weight
7.10 kg (15.7 lbs)
Form factor
Base Station
Manufactured
Between 1983 and 198x in USA
MPN
HEATHKIT-SA-002060A

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

Heathkit SA-2060A Manual submitted by RigReference
