Heathkit SA-2040 HF Antenna Tuner

 (0.0/5)  Add a story   View all stories (0)   Add to my shack



Frequency range

RX-range
3.5-30 MHz
TX-range
3.5-30 MHz
HAM bands
80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Stability
-
Tuning steps
-
Filters
-

Receiver

Modulations
All mode
Sensitivity
-
Selectivity
-
Receiver system
-
IF-frequencies
-
Image rejection
-
Audio output
-

Transmitter

Modulations
All mode
RF-Output
200 / 2000 W

Connections

Antenna
SO-239
Impedance
50Ω

Electrical

Power requirements
No power required
Current drain RX
-
TX
-

Physical

Dimensions (w×h×d)
368 × 146 × 352 mm (14.49 × 5.75 × 13.86 in)
Weight
6.80 kg (15.0 lbs)
Form factor
Base Station
Manufactured
Between 1979 and 1983 in USA
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-

Manuals, diagrams and brochures

Heathkit SA-2040 Antenna Tuner submitted by RigReference
