Identical to the Yaesu FT-200.

General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
Less than 100 Hz per 30 minutes after warm-up
Tuning steps
?
Memories
6 channels in 1 bank(s)

Receiver

RX-range
8-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28.5-29 MHz
Modulations
AM   CW   USB   LSB
Sensitivity
0.5 µV input S/N 10 dB
Selectivity
2.4 kHz @ - 6 dB, 4 kHz @ -60 dB
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
50 dB
Audio output
1 W @ 10% distortion into 8 Ohms

Transmitter

TX-range
8-10 m
3.5-4 / 7-7.5 / 14-14.5 / 21-21.5 / 28.5-29 MHz
Modulations
AM   CW   USB   LSB
RF-output
100 W (240 W input)

Connections

Antenna
-
Impedance
50-100Ω
Other
-

Electrical

Power requirements
External PSU
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
8.00 kg (17.7 lbs)
Form factor
Base Station
Manufactured
Between 197x and 198x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6407
MPN
TEMPO-ONE

Manuals, diagrams and brochures

Tempo 1 Instruction Manual PDF - 3.41 MB, submitted by Michael Ince
Tempo One Schematic diagram PDF - 505.2 kB, submitted by Michael Ince
