General characteristics

HAM bands
70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 kHz
Memories
200 channels in 1 bank(s)

Receiver

RX-range
400-490 MHz
Modulations
AM   FM   N-FM
Sensitivity
W-FM ≤ 0.25 μV (12 dB SINAD)
N-FM ≤ 0.35 μV (12 dB SINAD)
Selectivity
12.5 / 25 kHz
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
≥ 60 dB
Audio output
2 W @ 10% THD

Transmitter

TX-range
400-490 MHz
Modulations
FM   N-FM
RF-output
10 / 25 / 45 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC (±15%)
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
145 × 47 × 190 mm (5.71 × 1.85 × 7.48 in)
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 201x and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS / DCS
Accessories
-
RigReference ID
6416
MPN
ANYTONE-AT-000588-UHF
