Apache Labs Anan-100D Amateur HF/VHF SDR transceiver

 (0.0/5)  Add a story   View all stories (0)   Add to my shack


Image wanted



Login or Register to upload images

Supports seven fully independent receivers (software dependent). Each receiver can display 48/96/192/384/1152 kHz of spectrum. Full duplex, any split over the entire range. Full QSK. Transverter output. Ethernet connection.

Frequency range

RX-range
0.01-55 MHz
TX-range
10-160 m + WARC / 6 m
HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Stability
-
Tuning steps
1 Hz, Software defined
Filters
Software defined

Receiver

Modulations
Multiple (Software defined)
Sensitivity
-
Selectivity
Software defined
Receiver system
Direct conversion
IF-frequencies
Software defined
Image rejection
-
Audio output
1 W

Transmitter

Modulations
Multiple (Software defined)
RF-Output
1-100 W

Connections

Antenna
BNC
Impedance
50Ω

Electrical

Power requirements
13.8 V DC
Current drain RX
-
TX
-

Physical

Dimensions (w×h×d)
265 × 80 × 220 mm (10.43 × 3.15 × 8.66 in)
Weight
4.50 kg (9.9 lbs)
Form factor
Headless
Manufactured
Between 201x and 20xx in India
MPN

Other features

Memories
-
Usage
Amateur / Ham radio operators
