Three front ends of which two are independent phase coherent. Supported sampling rates: 48/96/192/384 kHz. Up to 1.152 MHz spectrum display. Full duplex, any split over the entire range. Ethernet connection. Diversity capable.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  10m
Frequency stability
?
Tuning steps
1 Hz, Software defined
Memories
?

Receiver

RX-range
0.01-55 MHz
Modulations
Multiple (Software defined)
Sensitivity
?
Selectivity
Software defined
Filters
Software defined
Receiver system
Direct conversion
IF-frequencies
Software defined
Image rejection
?
Audio output
1 W

Transmitter

TX-range
10-160 m + WARC / 6 m
Modulations
Multiple (Software defined)
RF-output
1-100 W

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
265 × 80 × 220 mm (10.43 × 3.15 × 8.66 in)
Weight
4.50 kg (9.9 lbs)
Form factor
Headless
Manufactured
Between 2014 and 20xx in India

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6423
MPN
APACHE-LABS-ANAN-000200D

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Apache Labs Anan-200D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Apache Labs Anan-200D is around:

  • USD 154.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 USD 155.00 Used / Okay KMac
