SDR, with a good electronics driven by a good software, 0.03µV sensitivity spectroscope HF and BF, drawn filters HF and BF, recording IF and BF to replays and improve filtering, All the functions of a advanced Rig in a "4 cigarettes packet" form factor.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m  2000m
Frequency stability
?
Tuning steps
1Hz

Receiver

RX-range
0.04 - 32 MHz
Modulations
AM   N-AM   AM-sync   FM   W-FM Stereo   CW   SSB   USB   LSB   FSK   DMR   RTTY
Sensitivity
0.03 µV
Selectivity
high IP3 (+29 dBm),
dynamic range (96 / 136 dB)
Filters
?
Receiver system
SDR
IF-frequencies
?
Image rejection
?
Audio output
none (USB)

Connections

Antenna
BNC
Impedance
50Ω
Other
-

Electrical

Power requirements
?
Current drain RX
?
TX
-

Physical

Manufactured
Between 20xx and 20xx in Germany
Dimensions (w×h×d)
115 × 33 × 91 mm (4.53 × 1.30 × 3.58 in)
Weight
220 gr (7.8 oz)
Form factor
Mobile

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
sensitivity 0.04µV
Accessories
?
MPN
BONITO-RADIOJET-001102S
