Kit

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.1-30 MHz
Modulations
AM   SSB
Sensitivity
AM: 2.5 µV (10 dB SNR @ 30% modulation
SSB/CW: 0.5 µV (10 dB SNR)
Selectivity
4 kHz (-6 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 45 MHz
2nd: 455 KHz
Image rejection
?
Audio output
?

Connections

Antenna
RCA (Tulip)
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-15V DC
Current drain RX
250 mA (no signal)
TX
-

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 199x and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4146
MPN
TEN-TEC-001254

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
It isn't half bad but it is half good. 8 years ago by Radio10

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Ten-Tec 1254. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Ten-Tec 1254 is around:

  • USD 42.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2009 USD 170.00 Used / Mint Radio10
