General characteristics

HAM bands
?
Frequency stability
± 10 p.p.m.
Tuning steps
25 kHz
Memories
55 channels in 1 bank(s)

Receiver

RX-range
156.300-162.025 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
21.4 MHz / 455 kHz
Image rejection
?
Audio output
2.8 W

Transmitter

TX-range
156.300-162.025 MHz
Modulations
FM
RF-output
1/25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
160 × 63 × 168 mm (6.30 × 2.48 × 6.61 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 19xx and 19xx

Other features

Usage
Marine / Navy
Features + options
-
Accessories
-
RigReference ID
6596
MPN
PRESIDENT-MC-008000-DSC

Manuals, diagrams and brochures

Manual President MC-8000 DSC PDF - 709.0 kB, submitted by Gerd
