General characteristics

HAM bands
None
Frequency stability
± 1.5 p.p.m.
Tuning steps
Channelized
Memories
72 channels in 1 bank(s)

Receiver

RX-range
156.050-163.275 / 155.500-161.425 MHz
Modulations
FM
Sensitivity
Better than 1 µV EMF @ 20dB SINAD
Distant: 119dBm (0,25 µV) @ 12dB SINAD
Local: 110dBm (0,7 µV) @ 12dB SINAD
Selectivity
12.5 kHz
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
70 dB
Audio output
2.5 W

Transmitter

TX-range
156.000-157.425 / 155.500-161.425 MHz
Modulations
FM
RF-output
1 / 25 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
9-16 V DC
Current drain RX
600 mA
TX
6 A max

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Mobile
Manufactured
Between 2018 and 20xx in UK

Other features

Usage
Marine / Navy
Features + options
IPx6 & IPx7
GPS/GLONASS/Beidou
NMEA0183/NMEA2000
AIS receiver
Accessories
-
RigReference ID
6625
MPN
RAYMARINE-RAY000073
