General characteristics

HAM bands
?
Frequency stability
± 10 p.p.m.
Tuning steps
Channelized
Memories
24 channels in 1 bank(s)

Receiver

RX-range
156.050-162.025 MHz
Modulations
FM
Sensitivity
-3 dB µV (20 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
1 W

Transmitter

TX-range
156.050-162.025 MHz
Modulations
FM
RF-output
1 / 4 W

Connections

Antenna
SMA
Impedance
?
Other
-

Electrical

Power requirements
7.2 V DC, 1350 mAh Nio-MH
Current drain RX
60-180 mA
TX
600-1200 mA

Physical

Dimensions (w×h×d)
65 × 143 × 40 mm (2.56 × 5.63 × 1.57 in)
Weight
320 gr (11.3 oz)
Form factor
Handheld
Manufactured
Between 20xx and 20xx

Other features

Usage
Marine / Navy
Features + options
-
Accessories
-
RigReference ID
6600
MPN
PRESIDENT-PM-001200-WP

Manuals, diagrams and brochures

Manual President PM-1200 WP PDF - 376.3 kB, submitted by Gerd
