Ailunce HA1G

General characteristics

HAM bands

?

Frequency stability

?

Tuning steps

?

Memories

250 channels in bank(s)

Receiver

RX-range

136-174 / 400-480 MHz
FM broadcast: 76-108 MHz

Modulations

FM   N-FM   W-FM

Sensitivity

-123 dBm (wide) / -124 dBm (narrow)

Selectivity

65 dB (wide) / 60 dB (narrow)

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

500 mW or more, distortion 5% or less

Transmitter

TX-range

GMRS (462-467 MHz)

Modulations

FM   N-FM

RF-output

5 / 0.5 W

Connections

Antenna

-

Impedance

?

Other

-

Electrical

Power requirements

Li-ion, 2800 mAh

Current drain RX

400 mA or less

TX

1.7 A or less

Physical

Dimensions (w×h×d)

56 × 126 × 37 mm (2.20 × 4.96 × 1.46 in)

Weight

300 gr (10.6 oz) With battery

Form factor

Handheld

Manufactured

Between 20xx and 20xx in China

Other features

Usage

General Mobile Radio Service

Features + options

IP67 waterproof GMRS handheld
NOAA weather
50 CTCSS / 112 DCS
Channel and priority scan
Wide / narrow bandwidth
Backlit keypad, BCLO
FM radio
USB-C charging

Accessories

-

RigReference ID

6736

MPN

AILUNCE-HA000001G

Similar rigs

Manuals, diagrams and brochures

No manuals yet for the Ailunce HA1G. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Ailunce HA1G. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Ailunce HA1G in Good condition is around:

• USD 66

Price History Chart

These estimates are based on the following prices:
