General characteristics

HAM bands
2m  70cm
Frequency stability
+/- 2.5 p.p.m.
Tuning steps
?
Memories
202 channels in 1 bank(s)

Receiver

RX-range
87.5-108 / 144-146 / 430-440 MHz
Modulations
AM   FM   N-FM   W-FM
Sensitivity
Main band: 0.2 µV or better (12 dB SINAD)
Sub band: 0.25 µV or better (12 dB SINAD)
Selectivity
12 kHz (-6 dB), 28 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 21.7 MHz / 450 kHz
2nd: 45.1 MHz / 455 kHz
Image rejection
?
Audio output
2W into 8 ohm @ 10% THD

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM   N-FM
RF-output
High: 50/35 W, Medium: 20/20 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
500-700 mA
TX
Max 11 A

Physical

Dimensions (w×h×d)
140 × 40 × 185 mm (5.51 × 1.57 × 7.28 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 2005 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
Detachable control head. Theft alarm. CTCSS & DCS. Twin RX. 1200/9600 bd packet and GPS option (EJ-50U). 10F3 digital voice board (EJ-47U) option (requires at least two similarly equipped radios). The DTMF mike is optional here in E
Accessories
-
RigReference ID
2337
MPN
ALINCO-DR-000635E

Manuals, diagrams and brochures

Alinco DR-635 Instruction manual PDF - Unknown size, submitted by RigReference
Alinco DR-635 Service manual PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DR-635E. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Alinco DR-635E is around:

  • EUR 97.00 ~ EUR 39.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2013 EUR 309.00 Used / Good thiecom.de
2010 EUR 249.00 New / Good thiecom.de
