The Yaesu FT-8800R dual bander operates on 2 meters and 70 centimeters. High power output is featured with 50 watts on 2 meters and 35 watts on 430 MHz. It is like having two radios in one with dedicated Volume and Squelch controls on each side. Built in features include: duplexer and CTCSS/DCS Encode/Decode. Over 1000 memories are available. It is WIRES compatible.
The FT-8800R features Yaesu's ARTS™ Auto-Range Transponder System, important in search-and-rescue applications. ARTS provides a "hand-shake" with other ARTS equipped transceivers and displays out of range or in range. A six character CW ID is also provided for your station every ten minutes during ARTS operation. The FT-8800R comes with a mobile mounting bracket, DC cord and MH-48A6J Up-Down, illuminated DTMF microphone.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 1054 channels in 1 bank(s)
Receiver
- RX-range
- 108-520 / 700-1000 MHz (Cellular blocked in the US)
- Modulations
- AM FM N-FM
- Sensitivity
- Better than 0.2 µV (12 dB SINAD)
- Selectivity
- 8 kHz (-6 dB), 30 kHz (-60 dB)
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA) - Modulations
- FM N-FM
- RF-output
- High: 50/35 W, Medium: 20/20 W, Low 2: 10/10 W, Low 1: 5/5 W
Connections
- Antenna
- SO-239
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 13.8V DC ±15%
- Current drain RX
- ?
- TX
- Max 8.5 A
Physical
- Dimensions (w×h×d)
- 140 × 42 × 168 mm (5.51 × 1.65 × 6.61 in)
- Weight
- 1,000 gr (2.2 lbs)
- Form factor
- Mobile
- Manufactured
- Between 2003 and 200x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- DTMF, CTCSS & DCS 9K6 packet ready. Twin RX
- Accessories
- -
- RigReference ID
- 4363
- MPN
- YAESU-FT-008800R
Manuals, diagrams and brochures
- Yaesu FT-8800R Brochure PDF - Unknown size, submitted by RigReference
- Yaesu FT-8800R Operation manual PDF - Unknown size, submitted by RigReference
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-8800R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Yaesu FT-8800R in Good condition is around:
- USD 200 ~ USD 300
- EUR 184 ~ EUR 276
These estimates are based on the following prices:
