ICOM IC-756 Pro

General characteristics

HAM bands

160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m

Frequency stability

?

Tuning steps

?

Memories

99 channels in 1 bank(s)

Receiver

RX-range

0.03-60 MHz

Modulations

AM   FM   CW   SSB   RTTY

Sensitivity

AM (10 dB S/N)
0.5-1.8 MHz: 13 µV
1.8-30 MHz: 2 µV (Pre-amp 1 on)
50-54 MHz: 1 µV
FM (12 dB SINAD)
28-30 MHz: 0.5 µV (Pre-amp 1 on)
50-54 MHz: 0.32 µV (Pre-amp 2 on)
SSB/CW/RTTY (10 dB S/N)
1.8-30 MHz: 0.16 µV (Pre-amp 1 on)
50-54 MHz: 0.13 µV (Pre-amp 2 on)

Selectivity

AM (BW=6 kHz)
>6 kHz (-6 dB), <15 kHz (-60 dB)
FM (BW=15 kHz)
>12 kHz (-6 dB), <20 kHz (-60 dB)
SSB/RTTY (BW=2.4 kHz)
>2.4 kHz (-6 dB), <2.8 kHz (-60 dB)
CW (BW=500 H

Filters

?

Receiver system

Triple-conversion superheterodyne

IF-frequencies

1st: 64.455 MHz
2nd: 455 KHz
3rd: 36 KHz

Image rejection

>70 dB

Audio output

?

Transmitter

TX-range

10-160 m + WARC/50-54 MHz

Modulations

AM   FM   CW   SSB   RTTY

RF-output

5-100/5-100 W (AM: 5-40 W)

Connections

Antenna

SO-239

Impedance

50 Ω

Other

-

Electrical

Power requirements

13.8V DC +/- 15%

Current drain RX

Max 3.5 A

TX

Max 23 A

Physical

Dimensions (w×h×d)

340 × 111 × 285 mm (13.39 × 4.37 × 11.22 in)

Weight

9.60 kg (21.2 lbs)

Form factor

Base Station

Manufactured

Between 2000 and 2001 in Japan

Other features

Usage

Amateur / Ham radio operators

Features + options

IF-DSP. Built-in auto-AT (HF: 16.7-150 ohms / 6 m: 20-125 ohms) Built-in keyer and RTTY demodulator. Twin RX

Accessories

-

RigReference ID

3161

MPN

ICOM-IC-000756-PRO

Manuals, diagrams and brochures

ICOM IC-756Pro Advanced Operating Guide.pdf PDF - Unknown size, submitted by RigReference



Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-756 Pro. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-756 Pro is around:

• USD 97.00 ~ USD 98.00

Price History Chart

These estimates are based on the following prices:
