General characteristics

HAM bands
160m  80m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  6m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.03-60 MHz
Modulations
AM   FM   CW   SSB   RTTY
Sensitivity
AM (10 dB S/N)
0.5-1.8 MHz: 13 µV
1.8-30 MHz: 2 µV (Pre-amp 1 on)
50-54 MHz: 1 µV
FM (12 dB SINAD)
28-30 MHz: 0.5 µV (Pre-amp 1 on)
50-54 MHz: 0.32 µV (Pre-amp 2 on)
SSB/CW/RTTY (10 dB S/N)
1.8-30 MHz: 0.16 µV (Pre-amp 1 on)
50-54 MHz: 0.13 µV (Pre-amp 2 on)
Selectivity
AM (BW=6 kHz)
>6 kHz (-6 dB), <15 kHz (-60 dB)
FM (BW=15 kHz)
>12 kHz (-6 dB), <20 kHz (-60 dB)
SSB/RTTY (BW=2.4 kHz)
>2.4 kHz (-6 dB), <3.6 kHz (-60 dB)
CW (BW=500 H
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>70 dB
Audio output
?

Transmitter

TX-range
10-160 m + WARC/50-54 MHz
Modulations
AM   FM   CW   SSB   RTTY
RF-output
SSB/CW/FM/RTTY: 5-100/5-100 W, AM: 5-40/5-40 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
Max 3.5 A
TX
Max 23 A

Physical

Dimensions (w×h×d)
340 × 111 × 285 mm (13.39 × 4.37 × 11.22 in)
Weight
9.60 kg (21.2 lbs)
Form factor
Base Station
Manufactured
Between 2002 and 2002 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
32 bit IF-DSP. Built-in auto-AT (HF: 16.7-150 ohms / 6 m: 20-125 ohms) Built-in RTTY demodulator and keyer. Twin RX
Accessories
-
RigReference ID
3162
MPN
ICOM-IC-000756-PRO-II

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Great Rig for the money! 7 years ago by N7RD
Great Bang for the buck 9 years ago by ke5zgi

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-756 Pro II. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-756 Pro II is around:

  • USD 411.00 ~ USD 757.00
  • GBP 496.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2012 USD 1250.00 Used / Good AB0DX
2011 GBP 1000.00 Used / Mint m6wsb
2009 USD 1300.00 Used / Good RFTim
2008 USD 1400.00 Used / Good W0MRM
