General characteristics
- HAM bands
- ?
- Frequency stability
- ?
- Tuning steps
- 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 kHz
- Memories
- 400 channels in 1 bank(s)
Receiver
- RX-range
- 0.495-1310 MHz
- Modulations
- AM FM W-FM
- Sensitivity
- AM 0.5-25 MHz: 1V (10 dB S/N)
FM 25-900 MHz: 0.32 µV (10 dB S/N)
FM 900-1300 MHz: 0.5 µV (10 dB S/N) - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- 45 dB
- Audio output
- ?
Connections
- Antenna
- SMA
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- ?V DC
- Current drain RX
- 95-170 mA
- TX
- -
Physical
- Dimensions (w×h×d)
- 58 × 86 × 27 mm (2.28 × 3.39 × 1.06 in)
- Weight
- 170 gr (6.0 oz)
- Form factor
- Handheld
- Manufactured
- Between 199x and 200x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 3214
- MPN
- ICOM-IC-R000002
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-R2. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the ICOM IC-R2 is around:
- EUR 118.00
These estimates are based on the following prices:
