General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
25 kHz
Memories
?

Receiver

RX-range
144-146 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 10.7 MHz
2nd: 455 KHz - Ceramic filter: CFT455F2
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 MHz
Modulations
FM
RF-output
1 W

Connections

Antenna
Built-in sweep
Impedance
50 Ω
Other
-

Electrical

Power requirements
9.6-16V DC
Current drain RX
45 mA
TX
450 mA

Physical

Dimensions (w×h×d)
122 × 51 × 175 mm (4.80 × 2.01 × 6.89 in)
Weight
1.20 kg (2.6 lbs) 10*NiCd included
Form factor
Unknown
Manufactured
Between 1979 and 198x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Illuminated dial PLL: SM5104GA
Accessories
-
RigReference ID
3445
MPN
KENWOOD-TR-002300
