2 x 6146B finals. PSU is in a separate cabinet

Frequency range

RX-range
10-80 m
TX-range
10-80 m
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
CW   SSB
RF-Output
80-100 W

Connections

Antenna
SO-239
Impedance
50/75 Ω

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
330 × 195 × 355 mm (12.99 × 7.68 × 13.98 in)
Weight
9.50 kg (21.0 lbs)
Form factor
Base Station
Manufactured
Between 197x and 197x
MPN
KENWOOD-TS-000515

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

Kenwood TS-515 User Manual submitted by RigReference
