General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB   FSK
Sensitivity
AM: 1 µV (10 dB (S+N)/N)
FM: 0.4 µV (20 dB quieting)
SSB: 0.25 µV (10 dB (S+N)/N)
CW: 0.18 µV (10 dB (S+N)/N)
Selectivity
AM/SSB/CW: 2.7 kHz (-6 dB), 4.8 kHz (-60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 8.2 MHz
2nd: 455 KHz
Image rejection
>70 dB
Audio output
?

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   SSB   FSK
RF-output
100 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
Mains
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
368 × 129 × 310 mm (14.49 × 5.08 × 12.20 in)
Weight
15.00 kg (33.1 lbs)
Form factor
Base Station
Manufactured
Between 1982 and 1984 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Tube hybrid
VOX
Accessories
-
RigReference ID
4237
MPN
YAESU-FT-000102

Manuals, diagrams and brochures

Yaesu FT-102 Instruction Manual PDF - Unknown size, submitted by RigReference
Yaesu FT-102 Technical Supplement PDF - Unknown size, submitted by RigReference

Upload relevant documents

Reviews & stories

Rating Title Submitted
Amatuer Radio Station KC1R 10 years ago by kc1r2012

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-102. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-102 is around:

  • AUD 16.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2002 AUD 400.00 Used / Good vk4qo
