General characteristics

HAM bands
2m
Frequency stability
Better than ±10 p.p.m. (-20°C to +60° C)
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz
Memories
130 channels in 1 bank(s)

Receiver

RX-range
137-174 MHz
Modulations
FM
Sensitivity
Better than 0.2 µV
Selectivity
12 kHz @ -6 dB / 28 kHz @ -60 dB
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
21.7 MHz & 450 kHz
Image rejection
≥ 70 dB
Audio output
3.5 W @ 4 ohm for 10% THD

Transmitter

TX-range
144-148 MHz
Modulations
FM
RF-output
50 / 25 / 10 / 5 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC (±10%), negative ground
Current drain RX
300-600 mA
TX
8 A (50 W) / 6 A (25 W) / 3 A (10 W) / 2 A (5 W)

Physical

Dimensions (w×h×d)
127 × 35 × 126 mm (5.00 × 1.38 × 4.96 in)
Weight
990 gr (2.2 lbs)
Form factor
Mobile
Manufactured
Between 2000 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
9K6 packet ready
Accessories
-
RigReference ID
4242
MPN
YAESU-FT-001500M

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
FT-1500 Long Lasting 4 years ago by kd4qhg
Very good packet radio 7 years ago by kb1chu
FT-1500M Good 2M 13 years ago by kb3iuu

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-1500M. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-1500M is around:

  • USD 4.00 ~ USD 3.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 129.00 Used / Good eBay
2020 USD 140.00 Used / Good Jim M.
2003 USD 144.00 New / Mint Dave
2002 USD 135.00 New / Mint kb1chu
2001 USD 99.00 New / Mint kd4qhg
