General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
12.5 / 25 kHz
Memories
?

Receiver

RX-range
144-146 / 430-440 MHz (Europe & Asia)
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz (Europe & Asia)
Modulations
FM
RF-output
High: 25/25 W, Low: 3/3 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
600 mA
TX
Max 7 A

Physical

Dimensions (w×h×d)
150 × 50 × 168 mm (5.91 × 1.97 × 6.61 in)
Weight
1.50 kg (3.3 lbs)
Form factor
Mobile
Manufactured
Between 1985 and 19xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4274
MPN
YAESU-FT-002700RH

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
FT-2700RH 9 years ago by n1mn

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-2700RH. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-2700RH is around:

  • USD 5.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1984 USD 350.00 New / Mint n1mn
