Yaesu FT-4700RH

Mobile VHF/UHF Transceiver

Specs Manuals (0) Reviews (1) Prices (3) Compare

The Yaesu FT-4700RH is a mobile VHF/UHF transceiver. It covers 144-146 / 430-440 MHz (Europe) or 144-148 / 430-450 MHz (USA). RF output is High: 50/40 W, Low: 5/5 W. Power requirements are 13.8V DC. Features include a detachable front panel and twin RX. Dimensions are 50 × 150 × 180 mm. Current drain is Max 0.6 A (RX) and Max 10 A (TX).

General characteristics

HAM bands: 2m 70cm
Frequency stability: ?
Tuning steps: 5 / 10 / 12.5 / 20 / 25 kHz
Memories: ?

Receiver

RX-range: 144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
Modulations: FM
Sensitivity: ?
Selectivity: ?
Filters: ?
Receiver system: ?
IF-frequencies: ?
Image rejection: ?
Audio output: ?

Transmitter

TX-range: 144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
Modulations: FM
RF-output: High: 50/40 W, Low: 5/5 W

Connections

Antenna: -
Impedance: 50 Ω
Other: -

Electrical

Power requirements: 13.8V DC
Current drain RX: Max 0.6 A
TX: Max 10 A

Physical

Dimensions (w×h×d): 150 × 50 × 180 mm (5.91 × 1.97 × 7.09 in)
Weight: 2.00 kg (4.4 lbs)
Form factor: Mobile
Manufactured: Between 1989 and 19xx

Other features

Usage: Amateur / Ham radio operators
Features + options: Detachable front panel. Twin RX
Accessories: -
RigReference ID: 4300
MPN: YAESU-FT-004700RH

We do our best to be accurate, but if you've spotted something wrong or incomplete, please let us know!

Manuals, diagrams and brochures

: No documents available for this particular model.

: Upload relevant documents

Reviews

Rating	Title	Submitted
	Ciril Slavinec-S57esc	15 years ago by ciril.slavinec

View all Yaesu FT-4700RH reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-4700RH. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Yaesu FT-4700RH in Good condition is around:

GBP 49
EUR 233 ~ EUR 1,400

Price History Chart

These estimates are based on the following prices:

Year	Historic price	Condition	Submitted by
2013	GBP 65.00	Used / Mint	2E0WET
2010	EUR 138.00	Used / Okay	eBay
1990	EUR 1400.00	New / Good	ciril.slavinec
