10m (UX-19E), 6m (UX-59A), 23cm (UX-129E), 2m SSB/CW (UX-S92E) and MW/76-950 MHz RX (UX-R91A) options.

General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
144-146 / 430-440 MHz
Modulations
FM
Sensitivity
0.18 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
144-146 / 430-440 MHz
Modulations
FM
RF-output
High: 50/35 W, Low: 5/5 W

Connections

Antenna
N-type
Impedance
50 Ω
Other
-

Electrical

Power requirements
11-16V DC
Current drain RX
0.85-1.4 A
TX
Max 12 A

Physical

Dimensions (w×h×d)
150 × 50 × 191 mm (5.91 × 1.97 × 7.52 in)
Weight
1.60 kg (3.5 lbs)
Form factor
Mobile
Manufactured
Between 1989 and 1990 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Twin RX
Accessories
-
RigReference ID
3179
MPN
ICOM-IC-000901E
