The Yaesu FT-757GXII is an affordable HF transceiver covering 160 to 10 meters and has ten memories. The general coverage receiver tunes from 150 kHz to 30 MHz. Power is 100 watts in CW, SSB, FM and 25 watts AM. The FT-757GXII features IF Shift, IF Notch and Noise Blanker.
This model replaces the earlier FT-757GX.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  10m
Frequency stability
?
Tuning steps
Continuous

Receiver

RX-range
150 kHz - 29.99999 MHz
Modulations
AM   FM   CW   USB   LSB   FSK
Sensitivity
SSB/CW: 0.25 µV
AM: 1 µV
FM: 0.5 µV (12 dB SINAD)
Selectivity
SSB/CW (W)/FSK: 2.7 / 4.5 kHz
CW (N): 0.6 / 1.3 kHz
AM: 6 / 18 kHz
FM: 15 / 30 kHz
(-6 dB / -60 dB)
Filters
?
Receiver system
Triple conversion superheterodyne
IF-frequencies
47.060 / 8.215 MHz / 455 kHz
Image rejection
≥ 70 dB
Audio output
1.5 W at 10% distortion into 4 ohms

Transmitter

TX-range
10-160 m + WARC
Modulations
AM   FM   CW   USB   LSB   FSK
RF-Output
100 W (AM: 25 W)

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
2 A
TX
19 A max

Physical

Manufactured
Between 1987 and 19xx
Dimensions (w×h×d)
238 × 93 × 238 mm (9.37 × 3.66 × 9.37 in)
Weight
5.20 kg (11.5 lbs)
Form factor
Base Station

Other features

Memories
None
Usage
Amateur / Ham radio operators
Features + options
Electronic Keyer
If Notch
IF Shift
Dual VFOs
Noise Blanker
100 Watts Output
Semi/Full Break-in CW
Attenuator
Speech Compressor
VOX
Electronic Keyer
Accessories
?
MPN
YAESU-FT-000757GX-II

Manuals, diagrams and brochures

Yaesu FT-757GXII Technical Supplement submitted by RigReference

Upload relevant documents

Reviews & stories

Yeasu FT-757gx is one fine radio!

Yaesu FT-757GX II, Desktop Shortwave Transceiver

30 years ago I owned a Yaesu 757gx. I loved that radio. I was studying for my ham ticket. I never could get the Morse code so I modified the rig to work on 11 meters. I lived in Washington, DC. a mile north of the White House in a seven story apartment building. The manager let me put up a tall antenna on the roof. With the 757gx I was able to talk all over our nation's capital. I loved the sound of SSB on 11 meters and I could talk all around the world when the conditions were right. The radio also had a general coverage receiver so I could listen to short wave stations. I sold my Yaesu 757gx to a friend at work who was a ham. I think he still has it. i wish I had never sold it. Now that there is no Morse code requirement I am again studying for my ham ticket and have been looking online to see if I could find a 757gx for sale. They have not made this rig in years but I see a number of them on eBay.. The build quality was so good I'm sure it would make an excellent classic ham radio today.

Written by tommy44 on Sep 11, 2019

Overall

Performance
Build quality
Features
User friendliness
Value for money
Aquired
Mint condition in 1989
USD 750.00

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-757GX II. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-757GX II is around:

  • EUR 245.00 ~ EUR 10.00
  • USD 163.00 ~ USD 49.00

These estimates are based on the following prices: (see all 7 prices)

Year Historic price Condition Submitted by
2018 USD 50.00 Used / Poor Necromonster
2017 EUR 250.00 Used / Good Lukas Thorwald Hey
2013 USD 400.00 Used / Okay drguyor
2013 EUR 300.00 Used / Good earman
2011 USD 330.00 Used / Good ac4m
