The Yaesu VX-5R is a handheld VHF/UHF transceiver. It covers 0.5-15 / 48-999 MHz for reception and transmits on 50-54 / 144-146 / 430-440 MHz bands. RF output power is selectable between High: 5/5/4.5 W, Low3: 2.5/2.5/2.5 W, Low2: 1/1/1 W, and Low1: 0.3/0.3/0.3 W. The VX-5R operates on 7.2V DC (internal) or 13.8V DC (external). Dimensions are 88 × 58 × 27 mm.
General characteristics
- HAM bands
- 6m 2m 70cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- ?
Receiver
- RX-range
- 0.5-15 / 48-999 MHz
- Modulations
- FM
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 50-54 / 144-146 / 430-440 MHz
- Modulations
- FM
- RF-output
- High: 5/5/4.5 W, Low3: 2.5/2.5/2.5 W, Low2: 1/1/1 W, Low1: 0.3/0.3/0.3 W
Connections
- Antenna
- SMA
- Impedance
- 50 Ω
- Other
- -
Electrical
- Power requirements
- 7.2V DC (internal), 13.8V DC (external)
- Current drain RX
- Max 150 mA
- TX
- Max 1.9 A
Physical
- Dimensions (w×h×d)
- 58 × 88 × 27 mm (2.28 × 3.46 × 1.06 in)
- Weight
- 255 gr (9.0 oz)
- Form factor
- Handheld
- Manufactured
- Between 199x and 200x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 4398
- MPN
- YAESU-VX-000005R
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu VX-5R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Yaesu VX-5R in Good condition is around:
- USD 141 ~ USD 218
- EUR 90 ~ EUR 120
These estimates are based on the following prices:
