Requires external speaker
The HA-410 is the 10m version of the Lafayette HA-460.

General characteristics

HAM bands
11m (CB)
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
28-29.7 MHz
Modulations
AM
Sensitivity
Less then 1 mV for 10 dB S/N
Selectivity
±3kHz at 6dB down, less then ±12kHz at 50dB down
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 5745 kHz
2nd: 455 kHz
Image rejection
?
Audio output
4 W @ 8 ohms

Transmitter

TX-range
28-29.7 MHz
Modulations
AM
RF-output
10

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC or mains (160 W max)
Current drain RX
?
TX
14 A max

Physical

Dimensions (w×h×d)
308 × 130 × 235 mm (12.13 × 5.12 × 9.25 in)
Weight
8.60 kg (19.0 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4483
MPN
LAFAYETTE-HA-000410

Manuals, diagrams and brochures

Lafayette HA-410 Installation and Operating Manual PDF - 1.19 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Rating Title Submitted
Hits well above its weight 9 years ago by GM4CID
Lafayette HA 410 10 years ago by TaylorSwiftFan

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Lafayette HA-410. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Lafayette HA-410 is around:

  • USD 1.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1970 USD 120.00 Used / Good GM4CID
