Frequency range

RX-range
144-146 MHz
TX-range
144-146 MHz
HAM bands
2m
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
FM   CW   SSB
Sensitivity
FM: 0.15 µV (10 dB)
SSB: 0.06 µV (10 dB)
Selectivity
?
Receiver system
Single conversion superheterodyne
IF-frequencies
10.7 MHz
Image rejection
?
Audio output
?

Transmitter

Modulations
FM   CW   SSB
RF-Output
10 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
13.8V DC or mains
Current drain RX
Max 1.4 A
TX
Max 2.9 A

Physical

Dimensions (w×h×d)
307 × 117 × 260 mm (12.09 × 4.61 × 10.24 in)
Weight
7.30 kg (16.1 lbs)
Form factor
Base Station
Manufactured
Between 1975 and 197x in West Germany
MPN
BRAUN-SE-000401

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
?
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.
