The WR-G33WSM is the first Software Defined Radio specifically designed for telemetry, audio engineering and stage production applications. The G33WSM receiver offers a the real-time spectrum analyzer with both linear and logarithmic scale, variable IF (intermediate frequency) filter and audio recording.

General characteristics

HAM bands
?
Frequency stability
10 p.p.m. (0 to 60° C)
Tuning steps
1 Hz kHz

Receiver

RX-range
30 - 1000 MHz
Modulations
FM   N-FM   W-FM
Sensitivity
FM, N-FM: 0.7 µV (30-500 MHz), 0.8 µV (500-1000 MHz)
W-FM: 2.0 µV (30-500 MHz), 2.5 µV (500-1000 MHz)
Selectivity
FM-N: 12 kHz (continuously variable)
FM-M: 30 kHz (continuously variable)
FM-W: 230 kHz
Filters
?
Receiver system
DDS-based dual-conversion superheterodyne with software-defined last IF stage and demodulator
IF-frequencies
1st: 109.65 MHz
2nd: 12 kHz
Image rejection
60 dB
Audio output
?

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
12V DC
Current drain RX
500mA
TX
-

Physical

Manufactured
Between 200x and 200x
Dimensions (w×h×d)
164 × 96 × 41 mm (6.46 × 3.78 × 1.61 in)
Weight
470 gr (1.0 lbs)
Form factor
Headless

Other features

Memories
?
Usage
Commercial / Land mobile communication
Features + options
USB (1.0 / 2.0) compatible computer connection.
Accessories
?
MPN
WINRADIO-WR-G000033WSM
