General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
Better than 0.34 p.p.m.
Tuning steps
?
Memories
100 channels in 1 bank(s)

Receiver

RX-range
0.1-30 MHz
Modulations
AM   USB   LSB
Sensitivity
J3E (SSB) <10 dB/µV for 20 dB SINAD
H3E (AM) <24 dB/µV for 20 dB SINAD
Selectivity
J3E (SSB) 350 Hz to 2700 Hz at -6 dB
H3E (AM) ±3.3 kHz at -6 dB
Filters
?
Receiver system
Double conversion super heterodyne
IF-frequencies
1st IF 70 MHz. 2nd 10.73 MHz
Image rejection
≥ 70 dB
Audio output
?

Transmitter

TX-range
1.6-30 MHz
Modulations
AM   USB   LSB
RF-output
250 W (PEP)

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
24 V DC - 10% +30%
Current drain RX
0.9 A
TX
13 A max

Physical

Dimensions (w×h×d)
?
Weight
4.50 kg (9.9 lbs)
Form factor
Base Station
Manufactured
Between 19xx and 19xx in Denmark

Other features

Usage
Marine / Navy
Features + options
Quick selection of 2182 kHz
Built-in two tone alarm: 1300 Hz and 2200 Hz with a duration of 45 secs
Accessories
-
RigReference ID
5546
MPN
SAILOR-T002130
