Vertex Standard VXD-300

General characteristics

HAM bands

2m  70cm

Frequency stability

± 0.5 p.p.m.

Tuning steps

12.5 / 20 / 25 kHz

Memories

512 channels in 1 bank(s)

Receiver

RX-range

134-174 / 403-470 / 450-512 MHz

Modulations

FM   DMR

Sensitivity

Analogue 12dB SINAD: 0.35 μV 0.22 μV typical
Digital: 5% BER: 0.3 μV

Selectivity

TIA603: 60 dB @ 12.5 kHz, 70 dB @ 25 kHz
TIA603C: 45 dB @ 12.5 kHz, 70 dB @ 25 kHz

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

70 dB

Audio output

500 mW @ 3% THD

Transmitter

TX-range

134-174 / 403-470 / 450-512 MHz

Modulations

FM   DMR

RF-output

VHF: 1/5 W, UHF: 1/4 W

Connections

Antenna

-

Impedance

50Ω

Other

-

Electrical

Power requirements

7.2 V DC (1300 or 2200 mAh Li-Ion)

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

131.5 × 63.5 × 36.2 mm (5.18 × 2.50 × 1.43 in)

Weight

430 gr (15.2 oz) with FNB-V117 battery

Form factor

Handheld

Manufactured

Between 2012 and 201x

Other features

Usage

Commercial / Land mobile communication

Features + options

IP 57

Accessories

-

RigReference ID

5632

MPN

VERTEX-STANDARD-VXD-000300
