General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
2.5 / 5 / 6.25 / 10 / 12.5 / 25 kHz
Memories
128 channels in 1 bank(s)

Receiver

RX-range
65-108 / 136-174 / 400-520 MHz
Modulations
FM   N-FM
Sensitivity
≤ 0.2 µV (12 dB SINAD)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
1 W

Transmitter

TX-range
136-174 / 400-520 MHz
Modulations
FM   N-FM
RF-output
1 / 4 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4 V DC Li-ion, 1800 mAh
Current drain RX
380 mA max
TX
1.5 A max

Physical

Dimensions (w×h×d)
110 × 58 × 32 mm (4.33 × 2.28 × 1.26 in) excl. antenna
Weight
670 gr (1.5 lbs)
Form factor
Handheld
Manufactured
Between 2011 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
LED Flashlight
CTCSS / DCS
DTMF
1750 Hz
VOX
PC programmable
Waterproof
Accessories
-
RigReference ID
6095
MPN
BAOFENG-UV-000005X

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
UV5X 9 years ago by k0mixham@gmail.com

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Baofeng UV-5X. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Baofeng UV-5X is around:

  • USD 18.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2015 USD 37.00 New / Mint k0mixham@gmail.com
2015 USD 37.00 New / Good k0mixham@gmail.com
