Very similar to the Baofeng UV-5R.
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ± 2.5 p.p.m.
- Tuning steps
- 2.5 / 5 / 6.25 / 10 / 12.5 / 25 kHz
- Memories
- 128 channels in 1 bank(s)
Receiver
- RX-range
- 65-108 / 136-174 / 400-480 MHz
- Modulations
- FM N-FM
- Sensitivity
- ≤ 0.2 µV (12 dB SINAD)
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- 1 W
Transmitter
- TX-range
- 136-174 / 400-480 MHz
- Modulations
- FM N-FM
- RF-output
- 1 / 4 W
Connections
- Antenna
- -
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 7.4 V DC Li-ion, 1800 mAh
- Current drain RX
- 380 mA max
- TX
- 1.5 A max
Physical
- Dimensions (w×h×d)
- 110 × 58 × 32 mm (4.33 × 2.28 × 1.26 in) excl. antenna
- Weight
- ?
- Form factor
- Handheld
- Manufactured
- Between 2011 and 201x in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Reversable LCD
LED Flashlight
CTCSS / DCS
DTMF
1750 Hz
VOX
PC programmable - Accessories
- -
- RigReference ID
- 6038
- MPN
- BAOFENG-A000052
