The Alinco DX-SR9 is the successor to the Alinco DX-SR8. It adds SDR and 10m coverage. The SDR system in DX-SR9 consists of I/Q signal output and a mixer circuit. It requires a high quality sound device (internal or USB-interface) and PC.
This radio lacks a CAT control interface.
General characteristics
- HAM bands
- 160m 80m 60m 40m 30m (WARC) 20m 17m (WARC) 15m 12m (WARC) 11m (CB) 10m
- Frequency stability
- ± 1 p.p.m.
- Tuning steps
- 10 Hz
- Memories
- 600 channels in 3 bank(s)
Receiver
- RX-range
- 135 kHz - 30 MHz
- Modulations
- AM FM CW USB LSB PSK31/63
- Sensitivity
- AM
0.15-1.8 MHz: 10 µV
1.8-30 MHz: 2 µV
FM 28-30 MHz: 0.5 µV
SSB 0.15-1.8 MHz: 1 µV
CW 1.8-30 MHz: 0.25 µV - Selectivity
- AM Narrow 2.4 kHz (-6 dB), 4.5 kHz (-60 dB)
AM/FM 6 kHz (-6 dB), 18 kHz (-60 dB)
SSB/CW 2.4 kHz (-6 dB), 4.5 kHz (-60 dB) - Filters
- 2.4 / 1 / 0.5 kHz
- Receiver system
- Double conversion superheterodyne / SDR
- IF-frequencies
- 1st: 71.75 MHz
2nd: 455 kHz - Image rejection
- 70 dB
- Audio output
- More than 2.0 W into 8 ohm 10% THD
Transmitter
- TX-range
- 10-160 m + WARC
5.3 MHz (USA only) - Modulations
- AM FM CW USB LSB PSK31/63
- RF-output
- FM/SSB/CW: 1/10/100 W, AM: 0.4/4/40 W
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11.7 - 15.8V DC
- Current drain RX
- 1 A max
- TX
- 20 A max
Physical
- Dimensions (w×h×d)
- 240 × 100 × 293 mm (9.45 × 3.94 × 11.54 in) including protrusions
- Weight
- 4.10 kg (9.0 lbs)
- Form factor
- Base Station
- Manufactured
- Between 2013 and 201x
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- Detachable front-panel
IF-shift
Noise blanker
RIT/TXIT
Electronic keyer - Accessories
- -
- RigReference ID
- 6045
- MPN
- ALINCO-DX-SR000009
Manuals, diagrams and brochures
- Alinco DX-SR9 Instruction manual PDF - Unknown size, submitted by RigReference
- Upload relevant documents
Reviews
| Rating | Title | Submitted |
|---|---|---|
| Good Back-Up Transceiver | 2 years ago by richard_n_08232 | |
| Don't waste your hard earned cash on this | 10 years ago by Charles |
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Alinco DX-SR9. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Alinco DX-SR9 in Good condition is around:
- USD 226
These estimates are based on the following prices:
