Similar to the AOR AR-6000

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
1 Hz to 999.999 kHz (2 Hz above 3 GHz)
Memories
2000 channels in 40 bank(s) @ 100 channels/second

Receiver

RX-range
0.009-3700 MHz (not guaranteed below 40 kHz)
Modulations
AM   AM-sync   FM   W-FM   CW   USB   LSB   TV
Sensitivity
AM (10 dB S/N, 6 kHz BPF)
0.04-0.05 MHz: 15 µV
0.05-0.06 MHz: 10 µV
0.06-0.07 MHz: 7 µV
0.08-0.1 MHz: 4 µV
0.1-25 MHz: 2 µV
25-2750 MHz: 1 µV
2750-3000 MHz: 1.7 µV
3000-3150 MHz: 4 µV
FM (12 dB SINAD, 15 kHz BPF)
25-2750 MHz: 0.4 µV
2750-3000 MHz: 0.6 µV
3000-3150 MHz: 0.6 µV
3150-4600 MHz: 0.5 µV
4600-5800 MHz: 0.7 µV
5800-6000 MHz: 1.5 µV
WFM (12 dB SINAD, 200 kHz BPF)
25-2750 MHz: 1.5 µV
2750-3000 MHz: 2.5 µV
3000-3150 MHz: 3.5 µV
SSB (10 dB S/N, 3 kHz BPF)
0.04-0.05 MHz: 6 µV
0.05-0.06 MHz: 4 µV
0.06-0.07 MHz: 3 µV
0.08-0.1 MHz: 1.5 µV
0.1-25 MHz: 0.7 µV
25-2750 MHz: 0.5 µV
2750-3000 MHz: 0.7 µV
3000-3150 MHz: 1.5 µV
Selectivity
200 Hz / 500 Hz / 3 kHz / 6 kHz / 15 kHz / 30 kHz / 100 kHz / 200 kHz / 300 kHz
Filters
?
Receiver system
Single (9 kHz-25 MHz) / double (25-220 MHz) / triple (220-360 MHz) conversion
IF-frequencies
1st: 1704.5 / 294.5 / 295 MHz
2nd: 45.05 / 294.5 / 45 MHz
3rd: 45.05 MHz
Image rejection
?
Audio output
?

Connections

Antenna
N-type
Impedance
50Ω
Other
-

Electrical

Power requirements
10-16 V DC
Current drain RX
200 - 1500 mA
TX
-

Physical

Dimensions (w×h×d)
220 × 97 × 304 mm (8.66 × 3.82 × 11.97 in)
Weight
3.50 kg (7.7 lbs)
Form factor
Base Station
Manufactured
Between 2013 and 20xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS/PL, DCS and DTMF-decoder
DSP with auto-notch and noise reduction
Dual watch (One frequency below 25 MHz and one above 25 MHz) or ±5 MHz offset RX (VHF/UHF only)
Five VFO's
RS-232C and USB
Real-time FFT spectrum display (400 kHz to 10 MHz width)
SD memory card slot for storing received audio and extended memory management
Video output
Voice inversion descrambler
Accessories
-
RigReference ID
6181
MPN
AOR-AR-005700D

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used AOR AR-5700D. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the AOR AR-5700D is around:

  • USD 9.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 USD 10.00 New / Mint Usama William
