General characteristics

HAM bands
80m  40m  20m  15m
Frequency stability
?
Tuning steps
10 / 100 Hz / 1 / 10 / 100 kHz / 1 MHz
Memories
10 channels in 1 bank(s)

Receiver

RX-range
3.5-3.9 / 7.0-7.3 / 14.0-14.35 / 21.0-21.45 MHz
Modulations
CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
3.5-3.9 / 7.0-7.3 / 14.0-14.35 / 21.0-21.45 MHz
Modulations
CW   SSB
RF-output
?

Connections

Antenna
SO-239
Impedance
?
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
420 mA
TX
4 A

Physical

Dimensions (w×h×d)
175 × 136 × 63 mm (6.89 × 5.35 × 2.48 in)
Weight
1.30 kg (2.9 lbs)
Form factor
Portable
Manufactured
Between 2011 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6242
MPN
CRKITS-KN-Q000010A

Manuals, diagrams and brochures

Crkits CRK10A Manual Rev A PDF - 1.04 MB, submitted by RigReference
