Frequency range

RX-range
160-10 m
TX-range
160-10 m
HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
All mode
Sensitivity
?
Selectivity
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
All mode
RF-Output
?

Connections

Antenna
SO-239 + Clamps / screws
Impedance
50/75Ω

Electrical

Power requirements
Mains (120/240 V AC)
Current drain RX
15 W
TX
?

Physical

Dimensions (w×h×d)
260 × 184 × 387 mm (10.24 × 7.24 × 15.24 in)
Weight
5.50 kg (12.1 lbs)
Form factor
Base Station
Manufactured
Between 1974 and 197x in USA
MPN
HEATHKIT-SB-000634

Other features

Memories
?
Usage
Amateur / Ham radio operators
Features + options
Clock
Alarm
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Heathkit SB-634 user manuals on eBay

Reviews & stories

Do you know this rig? Tell us something about it!

What's it worth

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the Heathkit SB-634. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the Heathkit SB-634 might be around:

  • USD 2.00
Year Historic price Condition Submitted by
1974 USD 199.95 New / Mint RigReference
