This newest radio is replacement to the Xiegu X108G and features an auto tuner.

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  10m
Frequency stability
± 2 p.p.m. (after 30 minutes of power on)
Tuning steps
?
Memories
?

Receiver

RX-range
0.5-30 MHz
Modulations
AM   CW   USB   LSB
Sensitivity
≥ 0.25 µV @ 12 dB SINAD (PRE: ON)
Selectivity
?
Filters
Optional: SSB 2.4 kHz / CW 300 Hz
Receiver system
SDR
IF-frequencies
?
Image rejection
?
Audio output
0.5 W @ 4Ω

Transmitter

TX-range
1.8-30 MHz
Modulations
AM   CW   USB   LSB
RF-output
1-20 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
12.5-14.5 V DC
Current drain RX
750 mA
TX
8 A

Physical

Dimensions (w×h×d)
120 × 45 × 210 mm (4.72 × 1.77 × 8.27 in)
Weight
1,000 gr (2.2 lbs)
Form factor
Portable
Manufactured
Between 2019 and 202x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
1.8" color LCD-screen
AGC
Noise blanker
S-meter
PO-meter
SWR-meter
CW-keyer
USB control port
Accessories
-
RigReference ID
6480
MPN
XIEGU-G000090

Manuals, diagrams and brochures

Xiegu G-90 User Manual PDF - 11.59 MB, submitted by Gerd

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Xiegu G90. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Xiegu G90 is around:

  • USD 447.00 ~ USD 410.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 USD 449.00 New / Mint Gary Pinson
2020 USD 430.00 New / Mint eBay
2020 USD 499.00 New / Mint RigReference
