SSB receive is available on HF only. The specifications give SW receive as 150 kHz-29.999 MHz; the FAQ on the product page says SSB receive covers 2.3-30 MHz.
Programming: Ola Radio app (iOS & Android) or CPS (model SW-9). In CHIRP, select UV-17PRO GPS.
Higher-power USB-C PD chargers may not start charging; use a 5 V / 2 A source.
General characteristics
- HAM bands
- 2m 1.25m 70cm
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- 1000 channels in 10 bank(s)
Receiver
- RX-range
- LW 153-279 kHz, MW 520-1710 kHz, SW 150 kHz-29.999 MHz
FM broadcast 64-108 MHz, AM airband 108-137 MHz
136-174 / 220-260 / 350-390 / 400-600 MHz
NOAA weather - Modulations
- AM FM W-FM SSB
- Sensitivity
- ?
- Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 136-174 / 220-260 / 400-470 MHz
- Modulations
- FM
- RF-output
- 10 / 5 / 2 W
Connections
- Antenna
- SMA
- Impedance
- ?
- Other
- -
Electrical
- Power requirements
- 7.4 V Li-ion battery, 2500 mAh USB-C charging (5 V / 2 A max.)
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- 67 × 165 × 41 mm (2.64 × 6.50 × 1.61 in)
- Weight
- ?
- Form factor
- Handheld
- Manufactured
- Between 2026 and 20xx
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- LW/MW/SW receive with SSB (USB/LSB) on HF
Tri-band transmit (VHF, 1.25 m, UHF), 10/5/2 W
1000 channels in 10 zones
Bluetooth data (app programming) and Bluetooth audio
2.0" colour TFT display
Dual SMA antenna ports (SMA-M / SMA-F)
NOAA weather receive
One-key frequency copy (frequency, CTCSS/DCS)
Fall detection (man-down) alert
USB-C charging - Accessories
- -
- RigReference ID
- 6822
- MPN
- BAOFENG-SW-000009
