General characteristics

HAM bands
2m
Frequency stability
± 10 p.p.m.
Tuning steps
5 / 10 / 12.5 / 20 / 25 / 50 / 100 kHz
Memories
None

Receiver

RX-range
136-174 MHz
Modulations
FM
Sensitivity
0.25 µV (12 dB SINAD)
Selectivity
7.5 kHz
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
21.4 MHz / 455 kHz
Image rejection
?
Audio output
2 W, 10% THD, 8 Ohms

Transmitter

TX-range
144.6-148 MHz
Modulations
FM
RF-output
10 / 45 W

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC +/- 15 %
Current drain RX
200 mA
TX
3.7-9 A

Physical

Dimensions (w×h×d)
142 × 42 × 160 mm (5.59 × 1.65 × 6.30 in)
Weight
?
Form factor
Mobile
Manufactured
Between 1995 and 199x

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS and DTMF
Accessories
-
RigReference ID
3769
MPN
RADIOSHACK-REALISTIC-HTX-000212

Manuals, diagrams and brochures

RadioShack HTX-212 Owner's Manual PDF - 334.0 kB, submitted by Gerd

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used RadioShack / Realistic HTX-212. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the RadioShack / Realistic HTX-212 is around:

  • USD 4.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1994 USD 150.00 New / Mint M. Eric Carr
