General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
60 channels in 1 bank(s)

Receiver

RX-range
144-146 MHz (Europe)
144-148 MHz (USA)
RX: 118-174 MHz
Modulations
AM   FM
Sensitivity
0.18 µV (12 dB SINAD)
Selectivity
15 kHz (-6 dB), 30 kHz (-60 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
>60 dB
Audio output
?

Transmitter

TX-range
144-146 MHz (Europe)
144-148 MHz (USA)
RX: 118-174 MHz
Modulations
FM
RF-output
High: 50 W, Medium: 10 W, Low: 5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC +/- 15%
Current drain RX
0.8-1 A
TX
Max 10.5 A

Physical

Dimensions (w×h×d)
?
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 1995 and 1998 in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS encoder (CTCSS decoder option)
Accessories
-
RigReference ID
2974
MPN
ICOM-IC-002000H

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
IC 2000 H 9 years ago by Shelcom2way

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-2000H. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-2000H is around:

  • USD 99.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 100.00 Used / Fair theoldgraycoat
