General characteristics

HAM bands
2m  70cm
Frequency stability
?
Tuning steps
5 / 10 / 12.5 / 20 / 25 / 50 kHz
Memories
20 channels in 1 bank(s)

Receiver

RX-range
144-148 / 430-440 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 / 430-440 MHz
Modulations
FM
RF-output
High: 3-5 W (depending on voltage), Low: 400 mW

Connections

Antenna
BNC
Impedance
50 Ω
Other
-

Electrical

Power requirements
5.5-16V DC
Current drain RX
35-150 mA
TX
Max 1.3 A

Physical

Dimensions (w×h×d)
60 × 173 × 34 mm (2.36 × 6.81 × 1.34 in)
Weight
490 gr (1.1 lbs) including batteries and antenna
Form factor
Handheld
Manufactured
Between 19xx and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
Full duplex possibility. CTCSS and DTMF option
Accessories
-
RigReference ID
4070
MPN
STANDARD-C-000500E
