General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
Modulations
CW   SSB
Sensitivity
≤ 0.1 µV
Selectivity
?
Filters
?
Receiver system
? conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
Modulations
CW   SSB
RF-output
200 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
12-14V DC
Current drain RX
250 mA
TX
20 A max.

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 197x and 19xx

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4134
MPN
SWAN-(CUBIC)-SS-000200A

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
SWAN SS-200A et. al. 8 years ago by daileyservices

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Swan (Cubic) SS-200A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

These estimates are based on the following prices:

Year Historic price Condition Submitted by
