General characteristics

HAM bands
80m  40m  20m  15m  10m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
10-80 m
26.9-27.5 MHz and 10-10.5 MHz (WWV)
Modulations
AM   CW   SSB
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
10-80 m
26.9-27.5 MHz and 10-10.5 MHz (WWV)
Modulations
AM   CW   SSB
RF-output
SSB: 260 W (PEP input), CW: 180 W (input), AM: 80 W (input)

Connections

Antenna
SO-239
Impedance
50/75 Ω
Other
-

Electrical

Power requirements
13.8V DC or mains
Current drain RX
0.5 A
TX
Max 20 A

Physical

Dimensions (w×h×d)
342.9 × 152.4 × 292.1 mm (13.50 × 6.00 × 11.50 in)
Weight
13.61 kg (30.0 lbs)
Form factor
Base Station
Manufactured
Between 197x and 197x in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
4232
MPN
YAESU-FT-000101

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Rating Title Submitted
Breakthrough Rig! 14 years ago by ZedderBRL

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-101. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-101 is around:

  • USD 5.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
1975 USD 425.00 Used / Good ZedderBRL
