Yaesu FT-60R

Handheld VHF/UHF Transceiver

View all reviews (11) Add a review Add to my shack



Login or Register to upload images

The Yaesu FT-60R dual-band 2 meter/440 MHz HT boasts 5 watts output on both bands. It also features wideband receive from 108-520 and 700-999.990 MHz (less cellular).
An Emergency Automatic ID system will automatically cause your FT-60R to transmit your callsign and engage the mic if you are disabled and unable to press the PTT switch. Two programmable keys are provided for your convenience. There is even a password feature to prevent unauthorized use of your radio. Radio to radio cloning is possible with the optional CT-27A cable.
Other refinements include: One touch NOAA weather, nine DTMF auto dialer memories, die-cast weather resistant case, ARTS Auto-range transponder system. There is also a Mono-band and Memory-only operating mode.

Frequency range

RX-range
108-520 / 700-999 MHz (cellular blocked in the US)
TX-range
144-146 / 430-440 MHz (Europe)
144-148 / 430-450 MHz (USA)
HAM bands
6m  70cm
Stability
better than ± 5 p.p.m.
Tuning steps
5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 kHz
Filters
?

Receiver

Modulations
AM   FM
Sensitivity
0.16 µV (12 dB SINAD - 140-150 MHz)
0.2 µV (12 dB SINAD - 420-470 MHz)
Selectivity
12 kHz (-6 dB), 35 kHz (-60 dB)
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 47.25 MHz
2nd: 450 kHz
Image rejection
?
Audio output
400 mW @ 8 Ohm

Transmitter

Modulations
FM
RF-Output
High: 5/5 W, Medium: 2/2 W, Low: 0.5/0.5 W

Connections

Antenna
SMA
Impedance
50 Ω

Electrical

Power requirements
Nominal: 7.2V DC (battery pack), 6-16V DC (external)
Current drain RX
45-125 mA
TX
Max 1.5 A

Physical

Dimensions (w×h×d)
58 × 109 × 30 mm (2.28 × 4.29 × 1.18 in)
Weight
370 gr (13.1 oz)
Form factor
Handheld
Manufactured
Between 2004 and 200x
MPN
YAESU-FT-000060R

Other features

Memories
1000 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
Alpha-tags. CTCSS & DCS. WIRES II. ARTS. Emergency Automatic ID (EAI).
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Yaesu FT-60R user manuals on eBay

Reviews & stories

Yaesu FT-60R Review

Yaesu FT-60R, Handheld VHF/UHF Transceiver

I've only had this radio for a few months. I bought it because it used the same battery and accessories as the VX-170. I needed a 70cm handheld for my role supporting backup inauguration communications and was about to buy the VX-177 when I found this radio for not much more. It worked well for that event.

I often find myself hitting the 0 key, which enables some sort of DTMF transmit function that really drives me crazy. I don't like it as much as the VX-170, but it does have a knob for the squelch.

Written by NE3R on Apr 4, 2009

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Good condition in 2009
USD 189.99

FT-60R

Yaesu FT-60R, Handheld VHF/UHF Transceiver

Love mine. Very compact, direct entry keyboard and use my on a daily activity.

Written by N2OBS on Oct 26, 2009

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Good condition in 2008
USD 150.00

FT 60R

Yaesu FT-60R, Handheld VHF/UHF Transceiver

Great little hand held - replaced my old FT408R finally and really like the options and features on this unit - two bands, built in tone generation, storage...finally had to give up on my old brick...

Written by W6TMV on Jun 8, 2010

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Good condition in 2007
USD 135.00
View all 11 reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FT-60R. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Yaesu FT-60R is around:

  • EUR 44.00 ~ EUR 83.00
  • USD 49.00 ~ USD 99.00
Year Historic price Condition Submitted by
2019 USD 145.00 Used / Mint John Richard Dorenbecher
2017 EUR 100.00 Used / Mint Lukas Thorwald Hey
2017 USD 175.00 New / Mint Drexal1956
2014 USD 179.00 New / Mint sanedraCDJ
2014 USD 179.00 New / Mint sanedraCDJ
2010 USD 150.00 Used / Good TODD
2010 USD 250.00 New / Mint KJ4VOV
2010 USD 150.00 Used / Good eBay
2010 EUR 169.00 New / Good thiecom.de
2009 USD 189.00 New / Mint KJ4KKI
