Depending on version 2, 8 or 16 channels.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
16 channels in 1 bank(s)

Receiver

RX-range
136-162 MHz
146-174 MHz
403-433 MHz
438-470 MHz
465-495 MHz
Modulations
FM
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
> 70 dB
Audio output
?

Transmitter

TX-range
136-162 MHz
146-174 MHz
403-433 MHz
438-470 MHz
465-495 MHz
Modulations
FM
RF-output
5 W max

Connections

Antenna
Proprietary
Impedance
50Ω
Other
-

Electrical

Power requirements
7.5V DC NiCad battery
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
59 × 140 × 40 mm (2.32 × 5.51 × 1.57 in) with battery
Weight
509 gr (1.1 lbs) with battery
Form factor
Handheld
Manufactured
Between 199x and 199x

Other features

Usage
Commercial / Land mobile communication
Features + options
CTCSS/PL or Select 5/5-tone CCIR
Accessories
-
RigReference ID
5219
MPN
MOTOROLA-GP-000300
