General characteristics

HAM bands
None
Frequency stability
± 10 p.p.m.
Tuning steps
25 kHz
Memories
48 channels in 1 bank(s)

Receiver

RX-range
156.050 - 163.275 MHz
Modulations
FM
Sensitivity
0.25 µV for 12 dB SINAD
Selectivity
12 / 25 kHz (-6 / -60 dB)
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
1st: 47.25 MHz
2nd: 450 kHz
Image rejection
70 dB
Audio output
700 mW @ 16 ohm for 10% THD

Transmitter

TX-range
156.025 - 157.425 MHz
Modulations
FM
RF-output
1 / 2.5 / 5 / 6 W

Connections

Antenna
-
Impedance
50Ω
Other
-

Electrical

Power requirements
12 V DC - 1150mAh Lithium-Ion
Current drain RX
330 mA
TX
1.6 A max

Physical

Dimensions (w×h×d)
62 × 142 × 45 mm (2.44 × 5.59 × 1.77 in)
Weight
335 gr (11.8 oz)
Form factor
Handheld
Manufactured
Between 2013 and 201x in Japan

Other features

Usage
Marine / Navy
Features + options
Submersible JIS-7 / IPX7
DSC Distress, All Ships, Group and Position Polling
One hand operation
Rubber armor on case for sure grip and durability
SOS Strobe light
Programmable channel names
12-channel GPS receiver
Large LCD (132 × 64 dots)
Accessories
-
RigReference ID
5625
MPN
STANDARD-HX000851

Manuals, diagrams and brochures

Standard HX851 Owner's Manual (English) PDF - 2.87 MB, submitted by RigReference

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Standard HX851. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Standard HX851 is around:

  • USD 42.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 45.00 Used / Good RigReference
