Estimated price when new in 2013: USD 1000.-

General characteristics

HAM bands
160m  80m  60m  40m  30m (WARC)  20m  17m (WARC)  15m  12m (WARC)  11m (CB)  6m  2m  10m  4m  2000m
Frequency stability
?
Tuning steps
?
Memories
?

Receiver

RX-range
0.02-170 MHz
Modulations
AM   AM-sync   FM   W-FM   CW   SSB   DSB   RTTY
Sensitivity
0.39 µV (CW, BW 500 Hz, 10 dB (S+N)/N)
Selectivity
>100 dB, Software defined
Filters
?
Receiver system
SDR / direct conversion
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
?
Modulations
AM   AM-sync   FM   W-FM   CW   SSB   DSB   RTTY
RF-output
5 W max

Connections

Antenna
SO-239
Impedance
50Ω
Other
-

Electrical

Power requirements
13.8 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Base Station
Manufactured
Between 2013 and 201x in Italy

Other features

Usage
Amateur / Ham radio operators
Features + options
-
Accessories
-
RigReference ID
6017
MPN
ELAD-FDM-DUO

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ELAD FDM-DUO. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ELAD FDM-DUO is around:

  • EUR 595.00 ~ EUR 676.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2019 EUR 750.00 Used / Mint OE3GAS
2015 EUR 1200.00 New / Mint PF1JM
